| 商品名称: |
吹雪机 |
| 产品型号: |
WS22/24/26 |
| 产品信息: |
抛雪机 |
| 详细信息: |
|
| WS22/24 Specifications |
| PRODUCT MODEL |
WS22 |
WS24 |
| ENGINE FACTORY |
BS |
BS |
| ENGINE MODEL |
12A31392880 |
12D31392881 |
| ENGINE SERIES |
800series |
900series |
| HORESPOWER |
6.5HP |
7.5HP |
| MAXIMUM SPEED |
3600+/-100RPM |
3600+/-100RPM |
| NUMBER OF CYLINDERS |
1 |
1 |
| BORE×STROKE(mm) |
68.3×55.9 |
68.3×55.9 |
| DISPLACEMENT |
205cc |
205cc |
| COMPRESSION RATIO |
8.2 |
8.2 |
| TORQUE |
8ft-ibs |
9 ft-ibs |
| OIL CAPACITY |
20 fl.oz |
20 fl.oz |
| GAS TANK CAPACITY |
2.7L |
2.7L |
| STARTING SYSTEM |
Manual/110 Volt Electric |
Manual/110 Volt Electric |
| DRY WEIGHT |
41.32lbs |
41.32lbs |
| ENGINE DIMENSIONS(L×W×H) |
394×259×395mm |
394×259×395mm |
| CLEARING WIDTH |
22”/55.9 cm |
24”/61 cm |
| HOUSING |
17”/43.2 cm |
17”/43.2 cm |
| THROWING DISTANCE |
3’-35’/0.9-10.7 m |
3’-35’/0.9-10.7 m |
| OIL TYPE |
Unleaded Oil |
Unleaded Oil |
| TYPE OF TRANSMISSION |
Friction Disc |
Friction Disc |
| CHUTE TURNING RADIUS |
200° |
200° |
| SPEED：FORWARD/REVERSE |
3 Forward/1 Reverse |
3 Forward/1 Reverse |
| GEAR CASE |
Aluminum |
Aluminum |
| IMPELLER DIAMETER |
12”/30.5 cm |
12”/30.5 cm |
| AUGER DIAMETER |
12”/30.5 cm |
12”/30.5 cm |
| TIRE SIZE |
13”х5”/33х12.7cm |
13”х5”/33х12.7cm |
| DIMENSIONS |
|
|
| LENGTH |
58”/147.3 cm |
58”/147.3 cm |
| WIDTH |
22”/55.9 cm |
24”/61 cm |
| HEIGHT |
39/99 cm |
39/99 cm |
| WEIGHT |
75 kg |
77 kg | |
|
| |
|
